Transducer, 0 to7500 psi, Output 1 to 5VDC MPN:G17M0115CD7500#
Transducer, 0 to7500 psi, Output 1 to 5VDC
This high-precision pressure transducer from Ashcroft is designed for a wide range of applications, including industrial, commercial, and scientific use. With a measurement range of 0 to 7,500 psi and an output of 1 to 5V DC, it provides accurate and reliable pressure readings. The device is suitable for use in harsh environments, with a NEMA 4X rating and IP65 protection against dust and water. Its compact design and DIN 43650 Form A connector make it easy to integrate into existing systems, making it an ideal choice for applications in oil and gas, chemical processing, and aerospace industries.
Top product features:
- Measures pressure from 0 to 7500 psi
- Outputs a signal of 1 to 5V DC
- Operates at temperatures up to 257 degrees F
Top product applications:
- Process Control Systems: The Ashcroft transducer can be used to measure pressure in industrial processes, providing a 1 to 5VDC output that can be easily integrated into control systems.
- Oil and Gas Industry: The high-pressure range of the transducer makes it suitable for applications in the oil and gas industry, such as measuring pressure in pipelines or wellheads.
- Power Plants: The transducer's ability to withstand high temperatures and pressures makes it a good fit for use in power plants, where it can be used to measure pressure in steam systems or other high-pressure applications.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 7,500 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/8 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP65, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.40
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.22
Product info last updated on April 23, 2026 6:10am UTC
Category: Pressure and Vacuum Measuring
