Transducer, 0 to 500 psi, Output 1 to 5VDC MPN:G17M0115CD500#
Transducer, 0 to 500 psi, Output 1 to 5VDC
Monitor pressure levels with precision and accuracy using the Ashcroft Series G2 Pressure Transmitter. Designed for a wide range of applications, this transducer measures pressures from 0 to 500 psi, providing a reliable output of 1 to 5V DC. Suitable for use in harsh environments, the transmitter features a NEMA 4X rating and IP65 protection. Ideal for industrial, commercial, and laboratory settings, this pressure transmitter is perfect for monitoring pressure in hydraulic systems, pneumatic systems, and other applications where precise pressure measurement is critical. Its compact design and ease of installation make it a valuable asset for any facility.
Top product features:
- Measures pressure up to 500 psi
- Outputs a 1 to 5V DC signal
- Operates over a temperature range of -40 to 257 degrees Fahrenheit
Top product applications:
- Pressure measurement in industrial processes
- Oil and gas exploration and production
- Automotive testing and calibration
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 500 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/8 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP65, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.20
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.28
Product info last updated on January 31, 2026 12:16am UTC
Category: Pressure and Vacuum Measuring
