Transducer, 0 to 300 psi, Output 1 to 5VDC MPN:G17M0115CD300#
Transducer, 0 to 300 psi, Output 1 to 5VDC
This high-precision pressure transducer from Ashcroft is designed for a wide range of applications, including industrial process control, laboratory research, and heavy industry. With a 0 to 300 psi measurement range and 1 to 5VDC output, it provides accurate and reliable pressure readings. The transducer's compact design and NEMA 4X rating make it suitable for harsh environments, while its IP65 rating ensures dust and water resistance. Its flexibility and accuracy make it an ideal solution for applications such as hydraulic systems, pneumatic systems, and chemical processing.
Top product features:
- Measures pressure up to 300 psi
- Provides a 1 to 5V DC output signal
- Operates in temperatures from -40 to 257 degrees F
Top product applications:
- Oil and Gas Industry: The transducer is used to measure pressure in oil and gas wells, allowing for accurate monitoring and control of pressure levels.
- Chemical Processing: The pressure transmitter is used in chemical processing plants to measure pressure in pipes and vessels, enabling operators to monitor and control process conditions.
- Hydraulic Systems: The transducer is used in hydraulic systems to measure pressure and provide feedback to control systems, allowing for precise control of fluid flow and pressure levels.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 300 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/8 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP65, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.30
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.29
Product info last updated on January 30, 2026 11:59pm UTC
Category: Pressure and Vacuum Measuring
