Transducer, 0 to 30 psi, Output 1 to 5VDC MPN:G17M0115CD30#
Transducer, 0 to 30 psi, Output 1 to 5VDC
This transducer from Ashcroft is a reliable and accurate pressure transmitter suitable for a wide range of industrial applications. It measures pressure from 0 to 30 psi and outputs a proportional 1 to 5V DC signal. The device is designed to withstand harsh environments with a NEMA 4X rating and operates within a temperature range of -40 to 257 degrees Fahrenheit. Its compact design and DIN 43650 Form A connector make it easy to integrate into existing systems. Ideal for use in oil and gas, chemical, and manufacturing industries, this transducer provides precise pressure measurements for improved process control and efficiency.
Top product features:
- Output of 1 to 5V DC
- Accuracy of +/-0.50 Percent Full Scale
- Operating Temperature Range of -40 to 257 Degrees F
Top product applications:
- Industrial Process Control: The transducer is used to measure and control pressure levels in industrial processes, such as chemical plants and manufacturing facilities.
- Oil and Gas Exploration: The pressure transmitter is used to measure wellhead pressure and other downhole pressures in oil and gas exploration and production operations.
- Hydraulic System Monitoring: The transducer is used to measure pressure levels in hydraulic systems, such as those found in construction equipment and heavy machinery.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 30 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/8 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP65, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.30
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.26
Product info last updated on February 1, 2026 2:40am UTC
Category: Pressure and Vacuum Measuring
