Transducer, 0 to7500 psi, Output 1 to 5VDC MPN:G17M0215CD7500#
Transducer, 0 to7500 psi, Output 1 to 5VDC
This high-performance pressure transducer from Ashcroft is designed for demanding applications, offering accurate measurements from 0 to 7500 psi. With a 1 to 5V DC output, it provides a reliable and consistent signal for various systems. The transducer is suitable for use in industrial settings, such as oil and gas, chemical processing, and power generation, where high-pressure measurements are critical. Its robust design and NEMA 4X rating ensure reliable operation in harsh environments, making it an ideal choice for applications where accuracy and durability are paramount.
Top product features:
- 0 to 7500 psi measurement range
- Output voltage of 1 to 5V DC
- Accuracy of +/-0.50 Percent Full Scale
Top product applications:
- Oil and Gas Industry: The Ashcroft pressure transmitter is used to measure the pressure of oil and gas in pipelines, wells, and storage tanks.
- Chemical Processing: The transducer is applied in chemical processing plants to monitor the pressure of chemicals in reactors, storage tanks, and pipelines.
- Power Generation: The pressure transmitter is used in power generation plants to measure the pressure of steam and other fluids in turbines, boilers, and pipelines.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 7,500 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/4 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.30
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.26
Product info last updated on February 15, 2026 11:48am UTC
Category: Pressure and Vacuum Measuring
