Transducer, 0 to 500 psi, Output 1 to 5VDC MPN:G17M0115EW500#
Transducer, 0 to 500 psi, Output 1 to 5VDC
This high-accuracy pressure transducer from Ashcroft is designed for precise measurement in a wide range of applications. With a 0-500 psi measurement range and 1-5VDC output, it's ideal for use in industrial, process control, and research settings. The transducer's rugged NEMA 4X rating and IP66 seal ensure reliable performance in harsh environments. Its compact 1/8 in NPT process connection and 4-pin M12 connector make it easy to integrate into existing systems. The transducer is suitable for applications such as pressure monitoring, flow measurement, and process control in industries like oil and gas, chemical processing, and power generation.
Top product features:
- Output range of 1 to 5V DC
- Accuracy of +/-0.50 Percent Full Scale
- Operating temperature range of -40 to 257 Degrees F
Top product applications:
- Industrial Process Control
- Oil and Gas Exploration
- High-Temperature Chemical Processing
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 500 psi, Electrical Connections 4-Pin M12 Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/8 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP66, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.70
- Package Width: 1.90
- Package Height: 4.10
- Package Weight: 0.22
Product info last updated on March 30, 2026 9:28am UTC
Category: Pressure and Vacuum Measuring
