Transducer, 0 to5000 psi, Output 1 to 5VDC MPN:G17M0215EW5000#
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0123392
Transducer, 0 to5000 psi, Output 1 to 5VDC
This high-precision pressure transducer from Ashcroft accurately measures pressures up to 5000 psi with an output of 1 to 5VDC. Ideal for industrial and process control applications, it offers +/- 0.50% accuracy and a compact 4-Pin M12 connector. The device is designed for use in harsh environments, with a NEMA 4X rating and IP67 protection against dust and water. Its wide temperature range (-40 to 257°F) and 9-36V DC power input make it suitable for a variety of applications, including oil and gas, chemical processing, and power generation. It ships in 12 days with a minimum order quantity of one unit.
Top product features:
- Measures pressure up to 5000 psi
- Output voltage range is 1 to 5V DC
- Operates over a temperature range of -40 to 257 degrees F
Top product applications:
- High-pressure oil and gas well monitoring systems
- Industrial process control in chemical plants and refineries
- Medical equipment calibration and testing in hospitals and research facilities
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 5,000 psi, Electrical Connections 4-Pin M12 Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/4 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.80
- Package Width: 1.80
- Package Height: 4.10
- Package Weight: 0.25
Product info last updated on January 27, 2026 2:49pm UTC
Category: Pressure and Vacuum Measuring
