Transducer, Vac to 30 psi, Output 1 to5VDC MPN:G17M0215EWVAC/30#
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0123304
Transducer, Vac to 30 psi, Output 1 to5VDC
This Ashcroft pressure transmitter is designed for use in a variety of applications, including industrial and commercial settings, where precise pressure measurement is required. With a vacuum to 30 psi measurement range and a 1 to 5VDC output, this transducer can be easily integrated into existing systems. Its high accuracy of +/-0.50 percent full scale and rugged NEMA 4X rating make it suitable for harsh environments. Ideal for use in HVAC, oil and gas, and chemical processing, this transmitter provides reliable and precise pressure measurement for improved efficiency and safety.
Top product features:
- Transmits pressure readings from -15 to 30 psi.
- Outputs a voltage signal of 1 to 5V DC.
- Withstands temperatures from -40 to 257 degrees F.
Top product applications:
- High-pressure oil and gas well monitoring systems
- Industrial process control systems for chemical plants and refineries
- Automotive and aerospace pressure measurement and control systems
Pressure Transmitter, Minimum Pressure -15 psi, Maximum Pressure 30 psi, Electrical Connections 4-Pin M12 Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/4 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.80
- Package Width: 1.60
- Package Height: 1.40
- Package Weight: 0.25
Product info last updated on January 30, 2026 10:58pm UTC
Category: Pressure and Vacuum Measuring
