Transducer, 0 to 500 psi, Output 1 to 5VDC MPN:G17MEK15DO500#
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0123252
Transducer, 0 to 500 psi, Output 1 to 5VDC
This high-accuracy pressure transducer from Ashcroft measures pressures from 0 to 500 psi with an output of 1 to 5VDC. Ideal for industrial applications, it offers +/-0.50% accuracy and operates within a wide temperature range of -40°F to 257°F. The compact design features a DIN 43650 Form A connector and a robust NEMA 4X rating for use in harsh environments. Suitable for various industries such as oil and gas, chemical processing, and manufacturing, this transducer provides reliable and precise pressure measurement for optimal system performance and process control.
Top product features:
- Measures pressure from 0 to 500 psi
- Provides an output voltage of 1 to 5V DC
- Operates in a temperature range of -40 to 257 degrees F
Top product applications:
- High-pressure oil and gas well monitoring systems
- Industrial process control applications in chemical plants and refineries
- Automotive and aerospace engine testing and calibration facilities
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 500 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 7/16 in, Process Connection Type SAE, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry Cable Gland, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.30
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.29
Product info last updated on March 30, 2026 12:41am UTC
Category: Pressure and Vacuum Measuring
