Transducer, 0 to 300 psi, Output 1 to 5VDC MPN:G17MEK15DO300#
Transducer, 0 to 300 psi, Output 1 to 5VDC
This high-precision pressure transducer from Ashcroft accurately measures pressures up to 300 psi with an output of 1 to 5VDC. Its compact design and rugged construction make it ideal for use in industrial settings, such as manufacturing, oil and gas, and chemical processing. The transducer's accuracy of +/-0.50 percent full scale and wide temperature range (-40 to 257°F) ensure reliable performance in harsh environments. Its NEMA 4X rating and IP67 protection also make it suitable for use in harsh environments and outdoors. Suitable for a variety of applications, including pressure monitoring and control systems.
Top product features:
- Measures pressure up to 300 psi
- Outputs a DC voltage signal between 1 and 5V
- Operates over a temperature range of -40 to 257 degrees Fahrenheit
Top product applications:
- Process control in oil and gas refineries for monitoring pressure in pipelines
- Pressure measurement in hydraulic systems for industrial machinery
- Monitoring pressure in water treatment plants for process control and optimization
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 300 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 7/16 in, Process Connection Type SAE, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry Cable Gland, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.10
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.28
Product info last updated on February 1, 2026 10:57am UTC
Category: Pressure and Vacuum Measuring
