Transducer, 0 to 100 psi, Output 1 to 5VDC MPN:G17MEK15DO100#
Transducer, 0 to 100 psi, Output 1 to 5VDC
This high-accuracy pressure transducer from Ashcroft measures pressure from 0 to 100 psi with an output of 1 to 5VDC. Its rugged design allows for operation in harsh environments, with a NEMA 4X rating and IP67 protection against dust and water. The transducer is suitable for a wide range of applications, including industrial process control, oil and gas exploration, and aerospace. Its compact size and DIN 43650 Form A connector make it easy to integrate into existing systems, while its high accuracy ensures reliable measurements in critical applications. Ideal for use in extreme temperatures.
Top product features:
- 0 to 100 psi measurement range
- Output of 1 to 5V DC
- Accuracy of +/-0.50 Percent Full Scale
Top product applications:
- Process control in oil and gas refineries
- High-pressure hydraulic systems in manufacturing plants
- Automated testing equipment in research and development laboratories
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 100 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 7/16 in, Process Connection Type SAE, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry Cable Gland, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.20
- Package Width: 1.50
- Package Height: 6.10
- Package Weight: 0.28
Product info last updated on February 5, 2026 7:17pm UTC
Category: Pressure and Vacuum Measuring
