Transducer, 0 to1000 psi, Output 1 to 5VDC MPN:G17M0115DO1000#
Transducer, 0 to1000 psi, Output 1 to 5VDC
This Ashcroft G2 series pressure transmitter is a reliable and accurate solution for a wide range of industrial applications. With a measurement range of 0 to 1000 psi and an output of 1 to 5VDC, it provides precise pressure readings in various industries such as oil and gas, chemical processing, and power generation. Its compact design and NEMA 4X rating make it suitable for harsh environments. The transmitter is also easy to install and maintain, with a DIN 43650 Form A connector and a male NPT process connection. It's ideal for use in high-temperature and low-temperature applications.
Top product features:
- 0 to 1000 psi pressure measurement capability
- 1 to 5V DC output for easy interfacing
- Accuracy of +/-0.50 Percent Full Scale for reliable readings
Top product applications:
- Oil and Gas Industry: The Ashcroft pressure transmitter is suitable for use in oil and gas applications, including monitoring pressure in wells, pipelines, and storage tanks.
- Process Control Systems: The transducer's 1-5VDC output makes it compatible with various process control systems, allowing for integration into industrial control systems for monitoring and controlling pressure in various processes.
- Hydraulic Systems: The pressure transmitter can be used to monitor pressure in hydraulic systems, such as those used in manufacturing, construction, and aerospace applications, providing accurate and reliable pressure measurements.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 1,000 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/8 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP65, Series G2, Wiring Entry Cable Gland, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.10
- Package Width: 1.40
- Package Height: 6.20
- Package Weight: 0.30
Product info last updated on February 1, 2026 12:17pm UTC
Category: Pressure and Vacuum Measuring
