Transducer, 0 to 300 psi, Output 1 to 5VDC MPN:G17M0115DO300#
Transducer, 0 to 300 psi, Output 1 to 5VDC
Accurate pressure measurement is crucial for a wide range of industrial applications, from manufacturing to oil and gas exploration. The Ashcroft Series G2 Pressure Transmitter provides reliable and precise pressure measurement, offering a 0 to 300 psi range and a 1 to 5VDC output. This transmitter is ideal for use in harsh environments, with a NEMA 4X rating and IP65 protection. Its compact design and DIN 43650 Form A connector make it easy to integrate into existing systems. Suitable for applications such as process control, monitoring, and testing, the Series G2 transmitter delivers accurate results in a rugged and reliable package.
Top product features:
- Measures pressure up to 300 psi
- Provides an output voltage of 1 to 5V DC
- Operates over a temperature range of -40 to 257 Degrees F
Top product applications:
- Industrial Process Control: This transducer is used to measure and monitor pressure levels in industrial processes, such as oil and gas refineries, chemical plants, and power generation facilities.
- Medical Equipment: The Ashcroft pressure transducer can be used in medical equipment, such as ventilators and anesthesia machines, to measure and control pressure levels that are critical to patient safety and well-being.
- Automotive Testing: This transducer is used in automotive testing facilities to measure and monitor pressure levels in engines, transmissions, and other vehicle systems, providing critical data for testing and development of new vehicles.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 300 psi, Electrical Connections DIN 43650 Form A Connector, Output 1 to 5V DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 3, Process Connection Gender Male, Process Connection Size 1/8 in, Process Connection Type NPT, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP65, Series G2, Wiring Entry Cable Gland, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 12 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.30
- Package Width: 1.40
- Package Height: 5.90
- Package Weight: 0.29
Product info last updated on February 21, 2026 8:30am UTC
Category: Pressure and Vacuum Measuring
