Pressure Transducer, Range 0 to 300 psi, MPN:G17MEK42M1300#
Pressure Transducer, Range 0 to 300 psi,
Monitor pressure levels with precision and accuracy using the Ashcroft Pressure Transducer, a reliable solution for a wide range of applications. With a range of 0 to 300 psi and an accuracy of +/-0.50 percent full scale, this transducer is ideal for use in industrial, commercial, and scientific settings. Its compact design and durable construction make it suitable for harsh environments, and its 4-20mA DC output provides easy integration with control systems. Suitable for applications such as process control, fluid measurement, and pressure monitoring, this transducer offers a cost-effective and efficient solution for measuring pressure levels.
Top product features:
- Measures pressure from 0 to 300 psi
- Provides a 4 to 20mA DC output
- Operates in temperatures up to 257 degrees F
Top product applications:
- Pressure Transducer for monitoring pressure in industrial processes such as oil and gas exploration
- Pressure Transmitter for measuring pressure in automotive applications such as fuel injection systems
- Pressure Sensor for use in medical devices such as ventilators and anesthesia machines
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 300 psi, Electrical Connections 4-Pin Mini-DIN Hirschmann G Series Connector, Output 4 to 20mA DC, Accuracy +/-0.50 Percent Full Scale, Number of Wires 2, Process Connection Gender Male, Process Connection Size 7/16 in, Process Connection Type SAE, Power Required 9 to 36V DC, NEMA Rating NEMA 4X, IP Rating IP67, Series G2, Wiring Entry 1/2 in FNPT Conduit Connection, Maximum Operating Temperature 257 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.50
- Package Width: 1.60
- Package Height: 3.70
- Package Weight: 0.18
Product info last updated on January 29, 2026 6:47am UTC
Category: Pressure and Vacuum Measuring
