Intrinsically Safe Transducer, 0 to 5 psi MPN:A4SBF0442D05#
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0120111
Intrinsically Safe Transducer, 0 to 5 psi
This Intrinsically Safe Transducer from Ashcroft is a reliable pressure measurement solution for demanding applications. Suitable for use in hazardous locations, it provides a 0 to 5 psi measurement range with high accuracy of +/-0.50% of full scale. The device features a DIN 43650 Form A connector and outputs 4 to 20mA DC, making it easy to integrate into various systems. Its compact design and rugged NEMA 4X and IP65 ratings ensure durability in harsh environments. Ideal for use in industries such as oil and gas, chemical processing, and power generation, this transducer offers precise pressure measurement and reliable performance.
Top product features:
- Measures pressure within a range of 0 to 5 psi
- Outputs a 4 to 20mA DC signal to indicate pressure levels
- Operates in a temperature range of -40 to 257 degrees Fahrenheit
Top product applications:
- Oil and Gas Industry Pressure monitoring in oil wells and pipelines.
- Chemical Processing Measuring pressure in chemical reactors and vessels.
- Power Generation Monitoring pressure in steam generators and turbines.
Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 5 psi, Electrical Connections DIN 43650 Form A Connector, Output 4 to 20mA DC, Accuracy +/-0.50 Percent of Full Scale, Number of Wires 2, Process Connection Gender Female, Process Connection Size 1/2 in, Process Connection Type NPT, Power Required 12 to 30V DC, NEMA Rating NEMA 4X, IP Rating IP65, Series A4, Wiring Entry With Mating Connection, Maximum Operating Temperature 257 Degrees F, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 50 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.90
- Package Width: 1.80
- Package Height: 4.70
- Package Weight: 0.55
Product info last updated on March 28, 2026 11:28pm UTC
Category: Pressure and Vacuum Measuring
