Solenoid Valve, 3-Way, 2-Position, Normally Closed, 1/8 in Pipe Size, 24/60V AC, Compact, Brass MPN:SC8356A002V

• The ASCO SC8356A002V is a compact, 3-way, 2-position solenoid valve with a normally closed starting configuration. It uses a direct acting operation to control the flow of fluids and gases such as air, inert gases, light oil, oxygen, steam, hot water, and water. The valve body is made of brass, and the sealing components are constructed with Viton material. It is designed to be mounted in either horizontal or vertical orientations and includes the electromagnetic coil. This valve provides automated control with a coil rated at 24/60V AC and 6.3 watts power consumption, environmental rating: Indoor, Outdoor.

  Key Features:

  • - Valve Design: 3-Way/2-Position, Normally Closed
  • - Operation Type: Direct Acting
  • - Body Material: Brass
  • - Seal Material: Viton
  • - Nominal Pipe Size: 1/8 in
  • - Orifice Diameter: 1/16 in
  • - Center Line Pipe Center Size: 1-13/16 in
  • - Maximum Operating Pressure Differential: 145 psi (Air/Inert Gas, Light Oil, Water)
  • - Maximum Fluid Temperature: 180°F
  • - Coil: Included, 24/60V AC, 6.3 W, Class F Insulation
  • - Electrical Connections: DIN
  • - Coil Enclosure: Without Junction Box, Watertight
  • - Environmental Rating: Indoor, Outdoor
  • - NEMA Enclosure Rating: 4
  • - IP Rating: 65
  • - Mounting Orientation: Horizontal or Vertical
  • - Dimensions: Overall Height 2-1/16 in
  • Overall Length 1-5/16 in
  • Overall Width 1 in
