Solenoid Valve, 3-Way, 2-Position, Normally Closed, 1/4 in Pipe Size, 24V DC, High Flow, FKM MPN:EV8316G381V24/DCDD

The ASCO EV8316G381V24/DCDD is a direct-acting, normally closed 3-way solenoid valve designed to control the flow of air, inert gases, and liquids. It features a 316 stainless steel body and includes the coil and sealing components required for operation. The valve operates with a nominal pipe size of 1/4 inch and uses NPTF threaded inlet and outlet connections. This valve provides automated flow control via electrical actuation, with a maximum fluid temperature rating of 130°F and an operating pressure differential for air and inert gases ranging from 0 to 130 psi. Its design supports use in indoor, outdoor, and hazardous environments with an explosion-proof, watertight coil enclosure.

Key Features:

• - Valve Design: 3-Way/2-Position, normally closed
• - Operation Type: Direct Acting
• - Body Material: 316 Stainless Steel
• - Seal Material: FKM
• - Orifice Diameter: 5/16 in
• - Nominal Pipe Size: 1/4 in
• - Connection Type: Inlet and Outlet NPTF threads
• - Center Line Pipe Center Size: 2-13/16 in
• - Flow Coefficient (Cv): 1.5
• - Electrical Voltage: 24V DC
• - Wattage: 0.55 W
• - Coil Enclosure: Explosion Proof, Watertight
• - Coil Insulation Class: F
• - Electrical Connections: 1/2 in Conduit with 18 in Leads
• - Environmental Rating: Hazardous, Indoor, Outdoor
• - Operating Pressure Differential Air/Inert Gas: 0 to 130 psi
• - Maximum Fluid Temperature: 130°F
• - Overall Dimensions: Height 5-11/16 in, Length 2-1/8 in, Width 3-5/16 in
• - Includes Coil and Seals
• - Standards: UL Listed
