Solenoid Valve, 2-Way, 2-Position, Normally Open, 1/2 in Pipe Size, 24V to 120V AC/DC, High Flow MPN:8210P034LF 24-120
The ASCO 8210P034LF 24-120 is a high-performance solenoid valve designed for controlling the flow of liquids or gases in automated systems. Its high flow rate and 2-way, 2-position operation make it ideal for a wide range of applications, including process control, industrial automation, and fluid handling. The valve's brass construction and NBR seal material ensure reliable performance in various environments, while its 24-120V AC/DC operation and Class F insulation provide flexibility and safety. Suitable for use in indoor and outdoor settings, this valve is a reliable choice for applications requiring precise control and high flow rates.
Top product features:
- High Flow capability
- Normally Open valve type
- Watertight coil enclosure
Top product applications:
- Liquid Level Control Systems
- Water Treatment Plants
- Chemical Processing Plants
The ASCO 8210P034LF 24-120 is a pilot-operated, 2-way high flow solenoid valve designed to control the passage of liquids or gases through an automated flow path. Its valve body is constructed of brass and features a nominal pipe size of 1/2 inch with NPT inlet and outlet connections. This valve is supplied with a coil rated for 24V to 120V AC/DC operation at 60 Hz frequency and includes the coil as part of the product.
Key Features:
- - Valve Type: High Flow, 2-Way, 2-Position, Normally Open
- - Material: Brass valve body with NBR seal material
- - Connections: 1/2 inch NPT inlet and outlet, NPT thread type
- - Operating Voltage: 24V to 120V AC/DC with 60 Hz frequency
- - Coil: Included with watertight enclosure and Class F insulation
- - Operating Pressure Differential Maximums: 350 psi Air/Inert Gas, 125 psi Light Oil, 150 psi Water
- - Operating Pressure Differential Minimums: 0 psi for Air/Inert Gas, Light Oil, and Water
- - Temperature Ratings: Ambient - minimum 14°F to maximum 140°F
- Fluid - maximum 180°F
- - Orifice Diameter: 5/8 inch
- - Mounting Orientation: Vertical
- - Electrical Connection: 1/2 inch Conduit Hub
- - Environmental ratings: Indoor and outdoor use
- no explicit rating for corrosive or hazardous environments
- - Wattage: 1.5 W
- - Standards: UL Listed
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.10
- Package Width: 4.50
- Package Height: 3.00
- Package Weight: 2.40
