Solenoid Valve, 2-Way, 2-Position, Normally Open, 1-1/2 in Pipe Size, 12V DC, High Flow, Brass, NBR MPN:8210G032LF 12/DC
The ASCO 8210G032LF 12/DC solenoid valve is a reliable and efficient solution for controlling the passage of air, inert gases, light oil, and water in various industrial applications. Its high flow design ensures rapid fluid movement, while its normally open, 2-position configuration allows for precise control over fluid flow. Suitable for use in a wide range of environments, from indoor to outdoor, this valve is ideal for applications such as HVAC systems, water treatment plants, and chemical processing facilities. Its durable brass construction and NBR seal ensure long-lasting performance and minimal maintenance.
Top product features:
- The ASCO 8210G032LF 12/DC is a pilot operated, high flow solenoid valve designed to control the passage of air, inert gases, light oil, and water.
- It features a normally open, 2-position configuration with a 1-1/4 inch orifice diameter and a 1-1/2 inch nominal pipe size.
- The coil enclosure is watertight for indoor and outdoor use.
Top product applications:
- Air compressor systems
- Industrial process control systems
- Water treatment systems
The ASCO 8210G032LF 12/DC is a pilot operated, high flow solenoid valve designed to control the passage of air, inert gases, light oil, and water. It features a normally open, 2-position configuration with a 1-1/4 inch orifice diameter and a 1-1/2 inch nominal pipe size. Intended for use with air, inert gases, light oil, and water within the specified operating pressure differentials and temperature limits (see Operating Pressure Differential and Fluid Temperature Maximum). Vertical mounting is supported
- coil enclosure is watertight for indoor and outdoor use.
Key Features:
- - Body Material: Brass
- - Operating Pressure Differential: 5 to 350 psi for air/inert gas, 5 to 125 psi for light oil, 5 to 150 psi for water
- - Fluid Temperature Maximum: 180°F
- - Ambient Temperature Range: 14°F to 140°F
- - Electrical Connections: 1/2 in Conduit Hub
- - Coil Included: Yes
- - Seal Material: NBR
- - Valve Type: High Flow
- - Valve Ways: 2-Way
- - Response Time: 1 second
- - Includes Seal: Yes
- - Inlet/Outlet Connection Type: NPTF with NPT thread type
- - Environmental Rating: Indoor, Outdoor
- - NEMA Enclosure Rating: 1, 2, 3, 3S, 4, 4X
- - Voltage: 12V DC
- - Wattage: 16.1 W
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.40
- Package Width: 7.50
- Package Height: 6.00
- Package Weight: 8.00
