Solenoid Valve, 2-Way, 2-Position, Normally Closed, 1/8 in Pipe Size, 24V AC, Compact, Brass, FKM MPN:SC8256B045V
The ASCO SC8256B045V compact, direct-acting 2-way/2-position solenoid valve is perfect for a wide range of applications, including controlling air, inert gases, light oil, and water in various industries. Its normally closed configuration and compact design make it ideal for use in tight spaces, while its NEMA 4/4X enclosure protection and IP66 ingress protection ensure reliable operation in harsh environments. With a fast response time of 20 msec and a compact size, this valve is perfect for use in applications such as water treatment, HVAC, and process control, where precise control and reliability are crucial.
Top product features:
- Compact design
- Direct-acting operation
- Normally closed configuration
Top product applications:
- Air Compressor System
- Automated Laboratory Equipment
- Medical Device Control Systems
The ASCO SC8256B045V is a compact, direct-acting 2-way/2-position solenoid valve with a normally closed configuration. The valve is rated to control media: air, inert gases, light oil, and water within the specified operating pressure and temperature ranges. Operation is actuated by an energized coil
- coil included with the product. This valve supports both horizontal and vertical mounting orientations and is rated for indoor use with NEMA 4/4X enclosure protection and IP66 ingress protection.
Key Features:
- - Body Material: Brass
- - Seal Material: FKM
- - Nominal Pipe Size: 1/8 in
- - Center Line Pipe Size: 1-13/16 in
- - Orifice Diameter: 1/8 in
- - Valve Design: 2-Way/2-Position
- - Valve Starting Configuration: Normally Closed
- - Operating Pressure Differential Maximum: 135 psi air/inert gas, 80 psi light oil, 126 psi water
- - Operating Pressure Differential Minimum: 0 psi for air/inert gas, light oil, and water
- - Fluid Temperature Maximum: 180°F
- - Coil Voltage: 24V AC
- - Coil Wattage: 6.3 W
- - Coil Insulation Class: F
- - Electrical Connections: DIN
- - Coil enclosure without a junction box
- enclosure rated watertight per product specifications
- - Includes Coil: Yes
- - Includes Seal: Yes
- - Environmental Rating: Indoor
- - Response Time: 20 msec
- - Overall Dimensions: Length 1-13/16 in, Height 2 in, Width 1 in
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 1.30
- Package Height: 3.10
- Package Weight: 0.30
