Solenoid Valve, 2-Way, 2-Position, Normally Open, 1-1/4 in Pipe Size, 120V AC, High Flow, Aluminum MPN:8215C063CSA
Free Shipping
In Stock
The ASCO 8215C063CSA solenoid valve is a high-performance solution for controlling air and vacuum flow in a variety of applications. Its direct-acting, 2-way, 2-position design allows for precise control and high flow rates, making it ideal for use in industrial processes, HVAC systems, and laboratory settings. The valve's aluminum body and NBR seals ensure durability and resistance to harsh environments, while its 120V AC operation and 15.4W power consumption make it energy-efficient and easy to integrate into existing systems. With a fast response time of 120 milliseconds, this valve is perfect for applications requiring quick and reliable control.
Top product features:
- High Flow capability
- Direct acting operation
- Normally open configuration
Top product applications:
- Air Compressor Systems
- Fuel Gas Control Systems
- Vacuum Systems
The ASCO 8215C063CSA solenoid valve is a direct-acting, 2-way, 2-position valve with a normally open starting configuration designed for controlling the flow of air and vacuum. It features an aluminum body and a valve design: 2-Way/2-Position
- direct acting. This valve operates within an ambient temperature range of 14°F to 140°F and can handle fluid temperatures up to 125°F. Environmental Rating: Hazardous, Indoor, Outdoor. It includes the coil as well as sealing components. The valve is operated at 120V AC, consuming 15.4 W of power at 60 Hz frequency.
Key Features:
- - Valve Design: 2-Way/2-Position, normally open configuration
- - Valve Type: High Flow, direct acting operation
- - Body Material: Aluminum
- - Media: Air, Fuel Gas
- - Operating Pressure Differential: 0 psi minimum, 25 psi maximum for air, fuel gas, and water
- - Orifice Diameter: 1-5/8 in
- - Nominal Pipe Size: 1-1/4 in with NPTF inlet and outlet connections
- - Coil Enclosure: Without Junction Box, watertight with Class F insulation
- - Electrical Connections: 1/2 in conduit with 18 in leads
- - Voltage: 120V AC at 60 Hz
- - Wattage: 15.4 W
- - Response Time: 120 milliseconds
- - Environmental Rating: Hazardous, Indoor, Outdoor
- - Seal Material: NBR
- - IP Rating: IP65
- - Overall Dimensions: Height 6-11/16 in, Length 5 in, Width 5-3/8 in
- - Includes coil and seal components
- - Standards: CSA, UL
- - NEMA Enclosure Rating: 1
- - Center Line Pipe Center Size: 3-5/8 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.40
- Package Width: 7.50
- Package Height: 6.10
- Package Weight: 4.10
