Solenoid Valve, 4-Way, 2-Position, Universal, 1/4 in Pipe Size, 120V AC, NAMUR Mount, Brass, NBR MPN:EF8345G001
The ASCO EF8345G001 Solenoid Valve is a versatile and reliable solution for controlling the flow of air, inert gases, light oil, and water in various industrial applications. Its pilot-operated design and explosion-proof coil ensure safe and efficient operation in high-pressure and high-temperature environments. With a compact brass body and NBR seals, this valve is suitable for use in a range of industries, including aerospace, pharmaceutical, and food processing. Its 4-way/2-position design and NAMUR mount make it easy to integrate into existing systems, providing precise control and minimizing downtime.
Top product features:
- The valve is pilot-operated, allowing for precise control over the flow of air, inert gases, light oil, and water.
- The valve features a brass body with NBR seals, providing a durable and reliable construction.
- The valve is designed for explosion-proof, watertight coil operation with Class F insulation, ensuring safe and reliable operation in a variety of environments.
Top product applications:
- Control the flow of air in pneumatic systems
- Use in water treatment applications to control flow and pressure
- Operate as a shut-off valve in industrial processes that use light oil or inert gases
The ASCO EF8345G001 is a pilot-operated, 4-way/2-position solenoid valve designed for controlling the flow of air, inert gases, light oil, and water. It includes an explosion-proof, watertight coil with Class F insulation. The valve features a brass body with NBR seals and pilot-operated actuation. This model is compatible with air, inert gas, light oil, and water within 10 to 150 psi differential and up to 180°F. The valve can be mounted horizontally or vertically and includes the coil and necessary seals.
Key Features:
- - Valve Design: 4-Way/2-Position with 2 discrete positions
- - Actuator Type: Single Air Pilot
- - Body Material: Brass
- - Seal Material: NBR (Buna-N)
- - Nominal Pipe Size: 1/4 in with 4 in centerline pipe spacing
- - Connection Type: NPTF inlet and outlet with NPT threads
- - Coil Enclosure: Explosion Proof, Watertight
- Coil Insulation Class: F
- - Electrical Connections: 1/2 in conduit with 18 in leads
- Operating Voltage: 120V AC at 60 Hz
- - Operating Pressure Differential: 10 to 150 psi for air, inert gas, light oil, and water
- - Maximum Fluid Temperature: 180°F
- - Orifice Diameter: 1/16 in
- - Valve Type: NAMUR Mount
- - Overall Dimensions: Height 4-11/16 in, Length 3 in, Width 2-1/16 in
- - Wattage: 10.1 W
- - Includes coil and seal
- - Standards: CSA, SIL, UL Listed
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.20
- Package Width: 4.20
- Package Height: 3.10
- Package Weight: 2.15
- California Prop 65 Warning: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
