Solenoid Valve, 2-Way, 2-Position, Normally Closed, 1/8 in Pipe Size, 24V DC, Compact, Brass, FKM MPN:U8256A002V
The ASCO U8256A002V is a compact, reliable, and efficient 2-way solenoid valve designed for a variety of applications. Suitable for indoor use, it controls the flow of air, inert gases, light oil, and water with a normally closed starting configuration. Its direct acting operation and FKM seals ensure precise control and durability. This valve is ideal for use in HVAC systems, laboratory settings, and industrial processes where precise control of fluids and gases is required. Its compact design and IP66 rating make it a versatile and reliable solution for a range of applications.
Top product features:
- Direct acting operation to control the flow of air, inert gases, light oil, and water
- Inlet and outlet NPTF threaded ports for 1/8 in nominal pipe size
- FKM seals for reliable sealing performance
Top product applications:
- Air control systems
- Inert gas systems
- Light oil systems
The ASCO U8256A002V is a compact, 2-way, 2-position solenoid valve with a normally closed starting configuration. Constructed with a brass valve body and FKM seals, it uses a direct acting operation to control the flow of air, inert gases, light oil, and water. The valve includes the coil and features an open frame enclosure with a coil insulation class F. It supports both horizontal and vertical mounting orientations and is intended for indoor use.
Key Features:
- - Connection Type: Inlet and outlet NPTF threaded ports, 1/8 in nominal pipe size
- - Dimensions: Overall length 1-5/16 in, width 1 in, height 2 in
- - Orifice Diameter: 1/16 in
- - Flow Capacity: Cv of 0.08
- - Differential pressure range: 0 to 220 psi for air, inert gas, light oil, and water
- - Electrical: 24 V DC voltage, 6.9 W coil wattage, 18 in lead electrical connections
- - Response Time: 20 milliseconds
- - Valve Design: Compact valve type, direct acting operation
- - Seals: FKM material
- - Environmental Ratings: IP66, NEMA 4 and 4X enclosure ratings
- - Includes coil and sealing components
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.10
- Package Width: 2.50
- Package Height: 4.00
- Package Weight: 0.41
