Solenoid Valve, 2-Way, 2-Position, Normally Closed, 1/8 in Pipe Size, 120V AC, Compact, FKM MPN:U8256A014V
The ASCO U8256A014V is a compact, direct-acting solenoid valve designed for precise control of air, inert gas, light oil, and water flow. Its stainless steel body and FKM seals ensure durability and resistance to corrosion, making it suitable for use in a variety of applications, including industrial processes, laboratory settings, and medical equipment. With a fast response time of 20 milliseconds and a compact design, this valve is ideal for use in tight spaces and high-precision applications. Its ease of installation and reliable operation make it a valuable addition to any system requiring precise control and flow management.
Top product features:
- Direct-acting design controls the flow of air, inert gas, light oil, and water
- FKM seals provide reliable sealing performance
- Compact design supports both horizontal and vertical mounting orientations
Top product applications:
- Process Control Systems
- Automotive Fuel Systems
- Medical Gas Systems
The ASCO U8256A014V is a direct-acting, normally closed compact solenoid valve designed to control the flow of air, inert gas, light oil, and water. Constructed with a stainless steel body and FKM seals, it supports both horizontal and vertical mounting orientations. The valve is rated for operation with air, inert gas, light oil, and water
- actuation is via an electrical coil with 18-inch leads, with operation limited to the specified maximum differential pressures. It operates at 120V AC and 60 Hz frequency and is rated for indoor environments with NEMA 4 and 4X enclosure protection.
Key Features:
- - Valve Design: 2-Way/2-Position, Normally Closed
- - Body Material: Stainless Steel
- - Seal Material: FKM
- - Nominal Pipe Size: 1/8 in with NPTF inlet and outlet connections
- - Orifice Diameter: 19/32 in
- Coefficient of Volume (Cv): 0.08
- - Maximum Operating Pressure Differential: 400 psi (Air/Inert Gas), 230 psi (Light Oil), 390 psi (Water)
- - Coil Enclosure: Open Frame with Class F insulation
- - Electrical Specifications: 120V AC, 6.3 W power consumption, 18 in Leads
- - Response Time: 20 milliseconds
- - Dimensions: 2 in height, 1-13/16 in length, 1 in width
- - Environmental Rating: Indoor
- NEMA Enclosure Rating: 4, 4X
- IP Rating: 66
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.80
- Package Width: 1.70
- Package Height: 3.60
- Package Weight: 0.35
