Diaphragm Valve, 8-23/64" L, PVDF MPN:1544012
Diaphragm Valve, 8-23/64" L, PVDF
The Asahi Diaphragm Valve is a versatile and reliable solution for various applications, including chemical processing, water treatment, and pharmaceutical manufacturing. Its 2-way design allows for precise control of fluid flow, while its PVDF body and PTFE diaphragm ensure durability and resistance to corrosion. With a Cv of 11 and a maximum operating pressure of 150 psi, this valve is suitable for a wide range of operating conditions. Its compact size and manual operation make it ideal for applications where space and simplicity are crucial.
Top product features:
- Manual operation allows for direct control over the valve's position
- Diaphragm material PTFE provides chemical resistance and durability
- Seal material PTFE ensures a leak-tight seal and long valve life
Top product applications:
- Chemical Processing
- Water Treatment Plants
- Pharmaceutical Manufacturing
Manual Diaphragm Valve, Coefficient of Volume (Cv) 11, Nominal Valve Size 1 1/4 in, Connection Type - Side 1 Butt Weld, Diaphragm Material PTFE, Seal Material PTFE, Maximum Pressure - Operating 150 psi, Operating Temperature - Maximum 210 Degrees F, Diaphragm Valve Type 2-Way, Body Material PVDF, Inlet Connection Gender Not Applicable, Overall Length 8.36 in, Operating Temperature - Minimum -40 Degrees F, ANSI Flange Class Not Applicable, Number of Flange Bolt Holes Not Applicable
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.00
Product info last updated on February 2, 2026 4:52pm UTC
Category: Pipes, Valves and Fittings
