Manual Motor Switch, 30 A, 2 P, 1 Phase, Handle, Contender Series, NEMA 3 MPN:EDSK-MC2
Manual Motor Switch, 30 A, 2 P, 1 Phase, Handle, Contender Series, NEMA 3
The Contender Series Manual Motor Switch from Appleton Electric is a reliable and efficient solution for controlling and protecting single-phase motors in a variety of applications. With a 30A current rating and 2-pole design, this switch is ideal for use in hazardous locations, including Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group E, F, G, and Class III, Div 1 and 2 areas. The switch includes a pilot light and operator handle, making it easy to monitor and control motor operation. Suitable for use in industrial settings, such as manufacturing, oil and gas, and chemical processing facilities.
Top product features:
- Operates in hazardous locations, meeting Class I, Div 1 and 2, Group C, D specifications, and Class II, Div 1 and 2, Group E, F, G specifications, and Class III, Div 1 and 2 specifications.
- Includes a pilot light for visual indication of operation.
- Operates at 30 A, 2 poles, 1 phase, with a handle for manual operation.
Top product applications:
- Motor control for single-phase AC motors up to 1 hp
- Motor control for three-phase AC motors up to 2 hp at 240V or up to 3 hp at 480V
- Motor control for hazardous locations, including Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group E, F, G, Class III, Div 1 and 2
Motor Switch, Current AC 30 A, Hazardous Location Specification Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group E, F, G, Class III, Div 1 and 2, Horsepower @ Single Phase - 120V AC 1 hp, Horsepower @ Three Phase - 240V AC 2 hp, Horsepower @ Three Phase - 480V AC 3 hp, Includes Pilot Light Yes, Number of Poles 2, Operator Handle, Phase Single, Starter Style NEMA, Terminal Connection Type Screw Terminals, Hub Diameter 0.75 in, Maximum Voltage Rating 600V AC, Mounting Style Surface
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 36 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.50
- Package Width: 7.20
- Package Height: 5.80
- Package Weight: 3.75
Product info last updated on February 16, 2026 10:42am UTC
Category: Industrial Electrical Controls and Automation
