Safety Relief Valve, 3/4 In, 10 psi, Bronze MPN:13211B10
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G1234195
Safety Relief Valve, 3/4 In, 10 psi, Bronze
This Safety Relief Valve is designed for low-pressure steam heating and supply boilers, providing reliable protection against excessive pressure. With a factory-set pressure of 10 psi and a pressure range of 5 to 15 psi, it ensures safe operation within a wide temperature range of 0 to 250 degrees F. The valve's steam capacity is 383 lb/hr, making it suitable for various applications. Its compact design and durable construction, featuring a cast bronze body and stainless steel spring, ensure long-lasting performance. Easy to install and test, this valve is a reliable solution for maintaining safe and efficient steam systems.
Top product features:
- Safety Relief Valve automatically releases excess pressure to prevent damage to the system
- Valve is designed to operate within a pressure range of 5 to 15 psi
- The valve is constructed with a cast bronze body and features a stainless steel spring for durability
Top product applications:
- Low Pressure Steam Heating
- Low Pressure Steam Supply Boilers
- Supply Boilers
Safety Relief Valve, Body Material Cast Bronze, Inlet Type MNPT, Outlet Type FNPT, Inlet Size 3/4 in, Outlet Size 3/4 in, Factory Set Pressure 10 psi, Pressure Range 5 to 15 psi, Steam Capacity (Lb./Hr.) 383 lb/hr, Disc Material EPDM, Overall Height 3 11/16 in, Application Low Pressure Steam Heating and Supply Boilers, Overall Length 2 13/16 in, Seat Material EPDM, Spring Material Stainless Steel, Temp. Range 0 Degrees to 250 Degrees F, Test Lever Test Lever Included, Standards CRN
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.70
- Package Width: 1.90
- Package Height: 3.80
- Package Weight: 1.05
Product info last updated on January 20, 2026 12:24am UTC
Category: Pipes, Valves and Fittings
