Andre XE-106 - Spring Mounts 5-5/8"L x 2-1/4"W x 4"H XE-106
Andre XE-106 - Spring Mounts 5-5/8"L x 2-1/4"W x 4"H
The Andre XE-106 Spring Mounts are designed to solve troublesome vibration problems in critical areas on concrete or wooden floors. These mounts feature a high static deflection spring and a two-piece cast iron housing, providing effective noise and vibration control. They are ideal for use in applications such as machinery, equipment, and heavy loads. The mounts also feature a non-skid elastomeric acoustic pad and slotted mounting holes for easy installation. With their built-in leveling device and hot dip galvanized springs, these mounts offer a reliable and durable solution for noise and vibration control. They are perfect for industrial settings.
Top product features:
- These mounts are preferred over most rubber mounts due to the high static deflection of the spring.
- The mounts feature a two piece cast iron housing for the spring.
- Resilient elastomeric snubbers on the inner panels prevent metal to metal contact and allow the spring to function properly.
Top product applications:
- Noise and vibration control applications in critical areas on concrete or wooden floors
- Vibration problems in industrial settings
- Noise control in commercial buildings
Type "x-100" series spring mounts with one inch deflection solves troublesome vibration problems. These mounts are preferred over most rubber mounts due to the high static deflection of the spring. "x-100" series spring mounts are designed for noise and vibration control applications in critical areas on concrete or wooden floors. The mount features a two piece cast iron housing for the spring. The mounts are provided with slotted mounting holes with a non-skid elastomeric acoustic pad on the base for easy bolting to the floor. Resilient elastomeric snubbers on the inner panels prevent metal to metal contact and allow the spring to function properly. These mounts have a built in leveling device (external or internal). These spring mounts can also be supplied with flat or non-skid neoprene top surfaces in case of internal level adjustment. All springs are hot dip galvanized.
Additional Information
- UNSPSC: 23153130
- Brand: Andre
- Color: Blue
- Package Quantity: 1
- Country of Origin: CA
- FOB Origin: ON
- Ships by: PARCEL
- Comes in a kit: No
- Newly added to catalog: No
- Item is on Clearance: No
- Contains Hazardous Materials: No
- CA Proposition 65 Applies: No
- Package Length: 6.00
- Package Width: 4.00
- Package Height: 4.00
- Package Weight: 5.00
Product info last updated on November 7, 2024 11:51am UTC
Category: Mounts, Pads and Vibration Dampers
