Vacuum Mtr/Blwr, Thru-Flow, 2 Stge, 2 Spd MPN:116227-00
Vacuum Mtr/Blwr, Thru-Flow, 2 Stge, 2 Spd
This high-performance vacuum motor/blower from Ametek Lamb is designed for demanding applications, offering a robust 26,000 RPM and 2-stage operation with 2 speed settings. Suitable for use in a variety of industries, including manufacturing, laboratory, and medical settings, this motor provides efficient and reliable airflow with a maximum air wattage of 316 W and vacuum rating of 106.9 CFM. Its compact design and universal AC/DC motor design make it easy to integrate into existing systems, while its open drip-proof enclosure and all-angle mounting capabilities ensure versatility and durability. Ideal for intermittent duty cycles and temperatures up to 40°C.
Top product features:
- Thru-Flow Motor/Blower design allows for efficient airflow
- Universal AC/DC motor design enables operation with various power sources
- Open Drip Proof motor enclosure design protects against dust and water ingress
Top product applications:
- Vacuum cleaning systems for industrial and commercial use
- Laboratory and research equipment for vacuum applications
- Medical equipment and devices that require vacuum technology
Vacuum Motor, Single Phase, Motor Design Universal AC/DC, Nameplate RPM 26,000 RPM, No. of Speeds 2, 120V AC Voltage, Full Load Amps 8.6 A, Non-Standard Frame, Motor/Blower Type Thru-Flow, Max. Amps 8.8 A, 60/50 Hz Hz, Motor Thermal Protection None, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Duty Cycle Intermittent, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Lug, Motor Mounting Position All Angle, Max. Air Watts 316 W, Vacuum Rating 106.9, CFM @ 2-In. Orifice 107 cfm
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 9.80
- Package Width: 6.80
- Package Height: 7.10
- Package Weight: 5.45
Product info last updated on January 16, 2026 12:24am UTC
Category: Motors
