Quick Disconnect Fitting, Barb, 3/8, Brass MPN:80195-08
Easily connect and disconnect hoses in compressed air systems with the Aignep USA Quick Connect Hose Coupling Socket. This universal coupling features a sleeve locking mechanism, providing a sealed and leak-resistant joint, and includes a poppet valve for flow control. Constructed from brass with a nickel-plated finish, it's designed for use with air tools and is compatible with universal interchange standards. Rated for 250 psi and 595 liters per minute, this coupling is ideal for applications such as pneumatic tools, air compressors, and industrial equipment, offering a convenient and reliable solution for compressed air systems.
Top product features:
- Provides a quick connect/disconnect coupling using a sleeve locking mechanism and provides a sealed, leak-resistant joint.
- Features a poppet valve to control air flow during connection and disconnection.
- Includes stainless steel locking balls and a protected seal made of nitrile material.
Top product applications:
- Compressed air systems
- Air tools
- Applications involving compressed air systems and air tools
The AIGNEP USA - 80195-08 is a quick connect hose coupling for use in compressed air systems and with air tools. Provides a quick connect/disconnect coupling using a sleeve locking mechanism and provides a sealed, leak-resistant joint. The coupling is constructed primarily of brass with nickel plating and features a poppet valve to control air flow during connection and disconnection, is rated for a maximum working pressure of 250 psi and has a rated flow capacity of up to 595 liters per minute. It is compatible with specified universal interchange standards for hose/coupling connections. Is for use with compressed air systems (as specified in its operating parameters).
Key Features:
- - Body and coupling size of 3/8 in, with a hose fitting size of 1/2 in and female hose fitting gender.
- - Connection type specified as NPTF with a 1/2"-14 thread size.
- - Features a brass body with a nickel-plated finish.
- - Includes stainless steel locking balls and a protected seal made of nitrile material.
- - Designed for applications involving compressed air systems and air tools.
- - Valve type: Poppet, included for flow control.
- - Is rated for operation within 0°F to 160°F.
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.70
- Package Width: 1.30
- Package Height: 1.30
- Package Weight: 0.32
