Safety Exhaust Coupler, 3/8", Brass MPN:80621-06
Safety Exhaust Coupler, 3/8", Brass
The Aignep USA Quick Connect Hose Coupling is a reliable and efficient solution for pneumatic applications. Designed for push/pull actuation, this coupling provides easy connection and disconnection without the need for hand tools. Its safety vent mechanism and integrated poppet valve ensure secure air flow control. Suitable for use in temperatures between 0°F to 180°F, this coupling is ideal for industrial applications where quick and safe connections are crucial. With a maximum flow rate of 595 L/min and a maximum working pressure of 220 psi, this coupling meets the demands of high-pressure pneumatic systems.
Top product features:
- Push/pull actuation for connection/disconnection without required hand tools
- Integrated poppet valve to control air flow
- Safety vent mechanism for locking
Top product applications:
- Pneumatic service
- Industrial applications
- General industrial use
The AIGNEP USA - 80621-06 is a designed for pneumatic service
- provides push/pull actuation for connection/disconnection without required hand tools. It features a push/pull mechanism with vented locking design and includes an integrated poppet valve to control air flow. The fitting is constructed from brass with zinc black anodized finish
- uses a nitrile seal. It is rated for a maximum flow rate of 595 L/min and a maximum working pressure of 220 psi at 70°F. The coupling is sized for 1/4 inch connections, with a 3/8 inch hose fitting size and 3/8"-18 thread size, made to Industrial interchange specifications.
Key Features:
- - Application: Pneumatic service
- - Material: Brass with zinc black anodized finish
- - Seal material: Nitrile
- - Coupling size: 1/4 in
- - Hose fitting size: 3/8 in, male gender
- - Thread size: 3/8"-18
- - Coupling component: Socket
- - Coupling locking: Safety vent mechanism
- - Valve: Integrated poppet type valve
- - Max. flow rate: 595 lpm
- - Max. working pressure: 220 psi @ 70°F
- - Overall length: 2 3/16 in
- - Max. outside diameter: 1 3/16 in
- - Temperature range: 0°F to 180°F
- - Interchange type: Industrial
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 1.40
- Package Height: 1.40
- Package Weight: 0.17
Product info last updated on January 19, 2026 7:55pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
