Splice Wire Connector, 250 kcmil Max, Yellow, None Insulation, 35 kV MPN:54513
Splice Wire Connector, 250 kcmil Max, Yellow, None Insulation, 35 kV
This ABB Splice Wire Connector is designed for high-voltage applications, featuring a maximum operating temperature of 194°F and a maximum voltage of 35 kV. Suitable for conductor material copper and wire type Class G, H, I, K, M, these connectors provide reliable connections for electrical systems. The short-barrel splice design allows for easy installation in tight spaces, making it ideal for use in industrial and commercial settings. With a maximum wire size of 250 kcmil, these connectors are perfect for applications such as power distribution, transmission lines, and heavy-duty electrical installations.
Top product features:
- Short-Barrel design for easy access and reduced tooling requirements
- Tin-plated barrel finish for corrosion resistance and improved electrical conductivity
- Seamless construction for increased reliability and reduced risk of electrical shorts
Top product applications:
- Outdoor electrical distribution systems
- Utility pole connections
- Industrial electrical panel connections
Short-Barrel Splice, Barrel Finish Tin Plated, Barrel Size Standard, Color Code Yellow, Die Code 62, For Conductor Material Copper, For Wire Type Class G, H, I, K, M, Material Copper, Maximum Voltage 35 kV, Minimum Wire Size 250 kcmil, Maximum Wire Size 250 kcmil, Number of Crimps 1, Overall Length 2.25 in, Maximum Conductors 1, Maximum Operating Temperature 194 Degrees F, RoHS Compliant Yes, Seam Style Seamless, Standards CSA Certified, UL Listed, Barrel Outside Diameter 0.77 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.30
- Package Width: 0.80
- Package Height: 0.80
- Package Weight: 0.10
Product info last updated on February 1, 2026 1:59pm UTC
Category: Electrical Connectors
