Ring Terminal, #6, #8, #10 Stud Size, 10 AWG, 600 V, Vinyl Insulated, Yellow, 500 PK MPN:MV10-610RK
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5776075
Ring Terminal, #6, #8, #10 Stud Size, 10 AWG, 600 V, Vinyl Insulated, Yellow, 500 PK
Elevate your electrical connections with 3M's high-quality Ring Terminals. These versatile connectors are designed for use with 10 AWG wires and are suitable for a wide range of applications, including industrial, commercial, and residential projects. The vinyl insulation and copper contacts ensure reliable connections and withstanding temperatures from -40°F to 221°F. With a maximum voltage rating of 600V, these terminals are ideal for use in high-voltage systems. The yellow insulation color provides easy identification, and the crimp termination style ensures secure connections. Perfect for use in electrical panels, control systems, and other applications where reliable connections are critical.
Top product features:
- Crimped termination for secure electrical connections
- Vinyl insulation provides electrical isolation and protection
- Tin-coated copper contact for reliable conductivity
Top product applications:
- Wire Harnesses
- Automotive Electrical Systems
- Control Panels
Ring Terminal, Insulation Color Yellow, Insulation Material Vinyl, Maximum Temperature 221 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 12 AWG, Maximum Wire Size 10 AWG, Termination Style Crimp, Tongue Width 0.39 in, Contact Finish Tin, Contact Material Copper, Standards CSA, RoHS 2011/65/EU, UL, Barrel Style Brazed, Minimum Operating Temperature -40 Degrees F, Overall Length 1.19 in, Package Quantity 500
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 4 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 2.60
Product info last updated on January 15, 2026 8:24am UTC
Category: Electrical Connectors
