Insulation-Displacement Wire Connector, 16 AWG Max, 2 Port, White, Polypropylene Insulation, 600 V MPN:560-BULK
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5733427
Insulation-Displacement Wire Connector, 16 AWG Max, 2 Port, White, Polypropylene Insulation, 600 V
This Insulation-Displacement Wire Connector from 3M is a reliable and efficient solution for connecting wires in various applications. With a maximum insulation diameter of 0.145 in and a temperature rating of 221 Degrees F, it can handle a range of wire sizes from 18 AWG to 16 AWG. Its polypropylene insulation and tin contact finish ensure high-quality connections. Ideal for use in industrial settings, this connector is suitable for applications such as electrical panel building, control panel assembly, and circuit board connections. Its compact design and ease of use make it a valuable addition to any electrical project.
Top product features:
- Insulation Displacement Connector allows for easy connection of wires without stripping insulation.
- Maximum Operating Voltage of 600 V ensures safe and reliable electrical connections.
- The connector's Polypropylene Insulation provides a durable and resistant barrier against electrical shock and environmental factors.
Top product applications:
- Wire harness assembly
- Electrical panel construction
- Device connection and termination
Insulation Displacement Connector, Color White, Connector Type Single U-Element, Insulation Material Polypropylene, Maximum Insulation Diameter 0.145 in, Maximum Temperature 221 Degrees F, Maximum Run Conductors 2, Maximum Run Wire Insulation Diameter 0.145 in, Minimum Run Wire Size 18 AWG, Maximum Run Wire Size 16 AWG, Maximum Tap Wire Insulation Diameter 0.145 in, Minimum Tap Wire Size 18 AWG, Maximum Tap Wire Size 14 AWG, Maximum Voltage 600 V, Number of Ports 2, Contact Finish Tin
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 4 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.70
Product info last updated on January 15, 2026 8:23am UTC
Category: Electrical Connectors
