Fork Terminal, #8 Stud Size, 18 AWG, 600 V, Bare Insulated, Red, Crimp Termination Only, 1000 PK MPN:M18-8FBK
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5532825
Fork Terminal, #8 Stud Size, 18 AWG, 600 V, Bare Insulated, Red, Crimp Termination Only, 1000 PK
Elevate your electrical connections with 3M's Fork Terminals, designed for reliable and efficient crimp termination. These high-quality terminals feature a copper contact and bare insulation, perfect for applications where a simple, cost-effective solution is required. Suitable for use in a variety of industries, including electrical, automotive, and aerospace, these terminals offer a maximum operating temperature of 347°F and a maximum voltage of 600V. With a minimum wire size of 22 AWG and a maximum wire size of 18 AWG, they provide flexibility in wire selection. Ideal for use in a range of applications, from industrial control panels to automotive wiring harnesses.
Top product features:
- Copper contact material provides excellent electrical conductivity.
- Brazed seam style ensures a strong and durable connection.
- Crimp termination style allows for a secure and reliable connection to a #8 stud.
Top product applications:
- Automotive Wiring Harness
- Electrical Panel Assembly
- Appliance Wiring
Fork Terminals, Contact Finish Tin, Contact Material Copper, Insulation Color Bare, Insulation Coverage None, Insulation Material None, Maximum Operating Temperature 347 Degrees F, Maximum Voltage 600 V, Maximum Wire Size 18 AWG, Stud Size #8, Termination Style Crimp, RoHS Compliant Yes, Seam Style Brazed, Standards CSA Certified, UL Listed, Barrel Length 0.25 in, Connection Material Copper, Connection Type Crimp, Insulation Type Non-Insulated, Minimum Wire Size 22 AWG, Overall Length 0.65 in
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.50
Product info last updated on January 15, 2026 8:19am UTC
Category: Electrical Connectors
