Ring Terminal, 1/2 in Stud Size, 10 AWG, 600 V, Vinyl Insulated, Yellow, Crimp Termination Only MPN:MV10-12RK
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5512017
Ring Terminal, 1/2 in Stud Size, 10 AWG, 600 V, Vinyl Insulated, Yellow, Crimp Termination Only
This 1/2 in stud size ring terminal is designed for use in a variety of applications where high voltage and temperature resistance are required. With a maximum operating temperature of 221 degrees F and a voltage rating of 600 V, it is suitable for use in electrical connections in harsh environments. The vinyl insulation provides excellent durability and resistance to wear and tear. The crimp termination style allows for secure and reliable connections. This product is ideal for use in industrial, commercial, and residential electrical installations, including motors, generators, and control panels. It meets CSA, RoHS, and UL standards.
Top product features:
- Vinyl insulation provides electrical isolation and protects against moisture and abrasion.
- Crimp termination allows for secure and reliable connection to a wire.
- Tin contact finish provides a durable and corrosion-resistant connection.
Top product applications:
- Automotive Wiring
- Electrical Panel Installation
- Heavy-Duty Equipment Wiring
Ring Terminal, Insulation Color Yellow, Insulation Material Vinyl, Maximum Temperature 221 Degrees F, Maximum Voltage 600 V, Minimum Wire Size 12 AWG, Maximum Wire Size 10 AWG, Termination Style Crimp, Tongue Width 0.75 in, Contact Finish Tin, Contact Material Copper, Standards CSA, RoHS 2011/65/EU, UL, Barrel Inside Diameter 0.14 in, Barrel Length 0.25 in, Barrel Outside Diameter 0.25 in, Barrel Style Brazed, Hole Spacing 0.38 in, Minimum Operating Temperature -40 Degrees F
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 3.40
Product info last updated on January 15, 2026 8:18am UTC
Category: Electrical Connectors
