Ring Terminal, #10 Stud Size, 10 AWG, 1, 000 V, Nylon Insulated, Yellow, Crimp Termination Only MPN:MNG10-10RK
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5487492
Ring Terminal, #10 Stud Size, 10 AWG, 1, 000 V, Nylon Insulated, Yellow, Crimp Termination Only
The 3M Ring Terminal is a reliable and durable solution for electrical connections. Featuring a #10 stud size and 10 AWG wire capacity, this terminal is suitable for a variety of applications, including industrial and commercial settings. The nylon insulation provides excellent protection against electrical shock and corrosion, while the crimp termination ensures a secure and long-lasting connection. With a maximum operating temperature of 221°F and a voltage rating of 1,000V, this terminal is perfect for use in high-temperature and high-voltage environments. Its CSA certification and UL listing ensure compliance with industry standards, making it an ideal choice for a range of applications.
Top product features:
- Crimp termination allows for secure and reliable connections
- Nylon insulation provides electrical insulation and protection
- Copper contact material ensures good electrical conductivity
Top product applications:
- Wire harness assembly
- Circuit protection and grounding
- Automotive electrical connections
Ring Terminal, Insulation Color Yellow, Insulation Coverage Partial Coverage, Insulation Material Nylon, Maximum Operating Temperature 221 Degrees F, Maximum Voltage 1,000 V, Minimum Wire Size 12 AWG, Maximum Wire Size 10 AWG, Termination Style Crimp, Tongue Width 0.38 in, Contact Finish Tin, Contact Material Copper, Standards CSA Certified, UL Listed, Barrel Inside Diameter 0.14 in, Barrel Length 0.25 in, Barrel Style Butted
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 5.00
- Package Width: 4.60
- Package Height: 2.70
- Package Weight: 2.45
Product info last updated on January 14, 2026 7:37pm UTC
Category: Electrical Connectors
