Fork Terminal, #8 Stud Size, 10 AWG, 600 V, Bare Insulated, Yellow, Crimp Termination Only, 500 PK MPN:M10-8FK
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5486214
Fork Terminal, #8 Stud Size, 10 AWG, 600 V, Bare Insulated, Yellow, Crimp Termination Only, 500 PK
The 3M Fork Terminal is a reliable and efficient solution for electrical connections, featuring a crimp termination style and a #8 stud size. Suitable for use in high-voltage applications up to 600V, this terminal is ideal for connecting 10 AWG wires. Its copper contact and tin finish ensure excellent conductivity and corrosion resistance. The terminal's non-insulated design allows for easy wire identification and crimping. With a maximum operating temperature of 347°F, it's perfect for use in a variety of applications, including industrial, commercial, and residential electrical systems. Its compact size and RoHS compliance make it a great choice for environmentally conscious projects.
Top product features:
- Copper contact material provides reliable electrical conductivity
- Tin contact finish enhances corrosion resistance and durability
- Crimp termination style allows for secure and efficient wire connection
Top product applications:
- Automotive Wiring Harness
- Electrical Panel Assembly
- Heavy Duty Electrical Connectors
Fork Terminals, Contact Finish Tin, Contact Material Copper, Insulation Color Bare, Insulation Coverage None, Insulation Material None, Maximum Operating Temperature 347 Degrees F, Maximum Voltage 600 V, Maximum Wire Size 10 AWG, Stud Size #8, Termination Style Crimp, RoHS Compliant Yes, Seam Style Brazed, Standards CSA Certified, UL Listed, Barrel Length 0.25 in, Connection Material Copper, Connection Type Crimp, Insulation Type Non-Insulated, Minimum Wire Size 12 AWG, Overall Length 0.73 in
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 4 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.50
Product info last updated on January 15, 2026 8:14am UTC
Category: Electrical Connectors
