Jobber Drill V HSS MPN:43792

Discount: See in Cart
Free Shipping
In Stock
Brand: Chicago-Latrobe
Part #: 43792
UPC: 662355437926
SKU
226-CXG-10P080
Jobber Drill V HSS

Introducing the Jobber Drill V HSS from Chicago-Latrobe - the ultimate tool for precise drilling applications. This high-speed steel (HSS) drill bit is designed with a TiCN coating that provides wear resistance and durability, making it perfect for metalworking industries such as aviation and automotive. With a size of V and a decimal equivalent of 0.3770, this drill bit offers versatility in terms of the range of materials it can work on, including steel, cast iron, and other metals. Its TiCN coating makes it ideal for high-pressure applications, allowing you to achieve superior performance when drilling at high speeds. Whether you are working on light fabrication or complex machining tasks, this Jobber Drill V HSS from Chicago-Latrobe will deliver the precision and performance needed to get the job done right.

Top product features:

  • Made with High Speed Steel (HSS) for durability and strength
  • Coated with TiCN for wear-resistance and high-pressure applications
  • Compliant with NAS 907 Type B standards for aerospace specifications

Top product applications:

  • Metalworking and machining industries
  • High-pressure drilling operations in aerospace manufacturing
  • Automotive and construction industries for creating precision holes
These drill bits meet National Aerospace Specification (NAS) 907 Type B. They have a TiCN coating that protects them from wear and is harder and more wear-resistant than a TiN coating.

Technical Specifications

  • Item Jobber Length Drill Bit
  • Drill Bit Size V
  • Decimal Equivalent 0.3770
  • Measurement System Letter
  • Material - Machining High Speed Steel
  • Finish - Machining TiCN
  • Drill Bit Point Angle 135 Degrees
  • Drill Bit Point Type Split Point
  • Coolant Fed Non-Coolant Through
  • Flute Type Spiral
  • Number of Flutes 2
  • Flute Length 3 5/8 in
  • Maximum Drilling Depth 1 1/2 in
  • Helix Angle 28 Degrees
  • Cutting Direction Right Hand
  • Spiral Direction Right Hand
  • Shank Type - Machining Straight
  • Shank Dia. 3/8 in
  • Shank Length 1 3/8 in
  • Overall Length 5 in
  • Depth:Dia. Ratio 4xD
  • Drill Length Class Jobber Length
  • Drill Point Length 0.0000 in
  • Drill Bit Grouping Individual
  • Series 150ASP-TC
  • Standards NAS 907 Type B
  • Aircraft Drill Yes
  • Drill Diameter Tolerance +0.0000 in /-0.0010 in
  • Primary Material Application Cast Iron, Stainless Steel, Steel, Tool and Die Steel
  • Primary Material Application ISO Code K, M, P

Manufacturer Details

  • Manufacturer: Chicago-Latrobe
  • Condensed Mfg Number: 43792
  • MPN: 43792

Label Details

  • Hazardous Material: N
  • Green Material Flag: N
  • Country of Origin: US
  • CA Prop 65 Wht Label: N

Classification Details

  • GDS Category Name: Jobber Length Drill Bits
  • GDS Family Name: Drilling and Holemaking
  • GDS Segment Name: Machining
  • UNSPSC: 27112801
  • UNSPSC Class ID: 28
  • UNSPSC Commodity Name: Tool attachments and accessories
  • UNSPSC Commodity ID: 01
  • UNSPSC Commodity Name: Drill bits
  • UNSPSC Family ID: 11
  • UNSPSC Family Name: Hand tools
  • UNSPSC Segment ID: 27
  • UNSPSC Segment Name: Tools and General Machinery

Shipping Details

  • Not For Sale In: HI AK PR
Related ASINs: B004MYGVFS
